Conference Indoor LED Cabinet P1.5 Multi Directional With 650cd / Sqm Brightness
Product Details:
| Place of Origin: | China |
| Brand Name: | Lemass |
| Certification: | RoHS, FCC, CE, CNAS, BIS, SGS |
| Model Number: | P1.5 Indoor conference LED screen display |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Cabinet packing (size: L543mm*W191mm*H696mm) |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10KK pixels/month |
|
Detail Information |
|||
| Name: | P1.5 Indoor Conference LED Screen Display | Size: | 640×480mm |
|---|---|---|---|
| Pixel Pitch: | 1.538mm | Resolution: | 416×312 |
| Features: | High Strength Aluminum Alloy Structure | Brightness: | 650cd/sqm |
| Lamp Type: | SMD1212 | Weight: | 7.7±0.05kg |
| High Light: | Conference Indoor LED Cabinet,650cd/Sqm Indoor LED Cabinet,Multi Directional P1.5 LED Screen |
||
Product Description
P1.5 Indoor conference LED screen display 640*480mm MH Series multi-directional adjustment
Description:
The highly reliable SMD technology is popularly known for its super-wide viewing angle for the LED screen. Moreover, there are numerous benefits of the MSD technology that makes the indoor LED display stand out in the crowd, such as higher contrast ratio, stable video deliverance, vibrant non-flickering images, high quality and vivid color performance. And it has higher refresh rate, high pixel density, super uniformity in color and most importantly, it is meager budget.
Quick Detail:
· High strength aluminum alloy structure
· Multi-directional adjustment
· All-round cooling system
· 160° ultra-wide viewing angle
· High refresh and high quality PWM drive IC
· Easy to install and maintain
Specifications:
| Parameter Item | MA1.5-G |
| Pixel Pitch (mm) | 1.538 |
| Pixel Density (pixels/sqm) | 422,500 |
| Module Resolution | 208x104 |
| Cabinet Resolution | 416×312 |
| Mask | Optional |
| Lamp Type | SMD1212 |
| Module Size (mm) | 320×160 |
| Module Weight (kg) | 0.47±0.05 |
| Cabinet Size (mm) | 640×480×65.5 |
| Cabinet Weight (kg) | 7.7±0.05 |
| Brightness (cd/sqm) | 650 |
| Gray Scale (Bit) | 12~16 |
| Color Temp (k) | 2500~10000 |
| Control System | Synchronous Control |
| Protection Level | Front IP31, Rear IP43 |
| Intelligent Storage | No |
| Frame Frequency (Hz) | 50/60FPS~120FPS (3D) |
| Refresh Rate(Hz) | 1920/3840(Optional) |
| Working Voltage | AC:100V~240V, 50/60Hz |
| Power Consumption (W/ m²) | Max:≤370,Ave:≤125 |
| Lifetime (hrs) | 100,000 |
| Operating Temp (℃) | -20～+40 |
| Storage Temp (℃) | -25~+60 |
| Humidity Range(Rh) | 10%~80%, Non-condensing |
| Pixel Correction | Brightness And Color Correction |
Details about the product:
Applications:
MH is widely used in commercial advertising, shopping malls, large occasions, etc.
