High Brightness Creative LED Display Screen P10.4 Transparent OEM ODM
Product Details:
| Place of Origin: | China |
| Brand Name: | Lemass |
| Certification: | RoHS, FCC, CE, CNAS, BIS, SGS |
| Model Number: | P10.4 indoor mesh transparent LED display |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Wooden case / Cabinet packing / Carton packing |
| Delivery Time: | 7-15 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10KK pixels/month |
|
Detail Information |
|||
| Name: | P10.4 Indoor Mesh Transparent LED Display | Size: | 1000x500x60mm / 500x500x60mm |
|---|---|---|---|
| Pixel Pitch: | H:10.4mm V:10.4mm | Resolution: | 96x48 48x48 |
| Features: | High Transparency | Brightness: | 3000cd/sqm |
| Lamp Type: | SMD2121 / 1921 | Weight: | 5+0.05kg / 2.5+0.05kg |
| High Light: | Creative LED Display Screen P10.4,Creative LED Display Screen ODM,OEM high brightness led display |
||
Product Description
P10.4 indoor mesh transparent LED display LMS-TF Pro series creative display
Description:
Where is Transparent LED Screens Used?
Transparent LED screens are similar to opaque screens, such as displaying information, data, and other details. However, the LED display screens do the same while blending perfectly with their surroundings. The cost-effective screens require less manufacturing time and are flexible for different uses. You might find these transparent LED display screens used in a wide variety of places. Here is a breakdown of some uses for LED screens.
Quick Detail:
· High transparency
· Ultra-thin
· Modular design
· Wide viewing angle
· High brightness
· XR wide color gamut
Specifications:
| Parameter Item | LMS-Tfree-Pro-F7.8 |
| Pixel Pitch (mm) | H:10.4 V:10.4 |
| Pixel Density (pixels/sqm) | 9,216 |
| Cabinet Resolution | 96 x 48 / 48 x 48 |
| Cabinet Size | 1000x500x60 / 500x500x60 |
| Transparency Rate | ≧70% |
| Pixel composition | SMD2121 / 1921 |
| Cabinet Weight (kg) | 5 / 2.5 |
| Brightness (cd/sqm) | 3000 |
| Gray Scale (Bit) | 16 |
| Color Temp (k) | 3000~10000 |
| Control System | Synchronous Control |
| Protection Level | IP31 |
| Intelligent Storage | No |
| Frame Frequency (Hz) | 50/60FPS |
| Refresh Rate (Hz) | 1920/3840(Optional) |
| Working Voltage | AC:100V~240V, 50/60Hz |
| Power Consumption (W/ m²) | Max:≤600,Ave:≤220 |
| Lifetime (hrs) | 100,000 |
| Operating Temp (℃) | 0~+40 |
| Storage Temp (℃) | -20~+60 |
| Humidity Range(Rh) | 35%~85%, Non-condensing |
| Pixel Correction | Brightness And Color Correction |
Details about the product:
Applications:
Bring wider commercial applications, and let the large media advertising market, etc.
